Pixel pitch: the complete guide

Pixel pitch decides how close viewers can stand, how sharp the image looks, and how much the wall costs. The full ladder from 0.6 mm to 10 mm+, with real series counts from our catalog — plus a calculator that turns your viewing distance into a pitch.

Last verified: 2026-09-26 · Specs transcribed from official vendor pages and spec sheets.

Large-format LED billboards in Times Square at night
Illustrative photo: large-format LED billboards. Viewing distance is what makes pixel-pitch choice matter.Photo by gtrwndr87, CC BY-SA 2.0, via Flickr

The short answer

Match the pitch to the closest viewer. Minimum viewing distance in meters is roughly the pitch in millimeters: P2.6 for viewers from 2.6 m, P3.91 from 4 m, P1.5 from 1.5 m. Finer pitch costs more per square meter and buys nothing your audience cannot see. Series counts below come from the 272 series in our catalog that publish pitch figures, across 14 manufacturers (verified 2026-09-26).

Viewing distance → pitch calculator

Enter how close the nearest viewer gets. The rule of thumb gives you the coarsest pitch that still looks seamless; the premium pick is for text-heavy or camera-facing content.

The pitch ladder, with real catalog data

Every row is counted from our catalog — the number of series that publish a pitch in that class. One series can span several pitches, so rows do not sum to the catalog total.

Pitch classExact values groupedSeries in catalogPixels / m² (≈)Min. viewing distanceTypical use
Finer than P0.90.60–0.78 mm25≈2.0M (at 0.7)< 1 mControl rooms, virtual production
P0.90.90–0.9375 mm451,234,568≈ 1 mBroadcast studios, control rooms
P1.21.2–1.3 mm72694,444≈ 1.2 mIndoor fixed installs
P1.51.5–1.6 mm102444,444≈ 1.5 mRetail, corporate lobbies
P1.91.8–2.0 mm123277,008≈ 2 mIndoor events, houses of worship
P2.52.5–2.583 mm47160,000≈ 2.5 mIndoor rental, exhibitions
P2.62.6 / 2.604 mm65147,929≈ 2.6 mStage rental, camera-facing walls
P2.92.9–2.976 mm44118,906≈ 3 mAll-round rental, indoor/outdoor
P3.913.75–3.91 mm10165,544≈ 4 mTouring workhorse, concerts
P4.814.8 / 4.81 mm3043,222≈ 5 mLarge outdoor surfaces
P5.9 and coarser5.0–100 mm20928,727 (P5.9) → 10,000 (P10)6 m+Billboards, stadiums, facades

Pixels per m² = (1000 / pitch)² at the nominal pitch — pure math, no vendor claims involved. A handful of non-standard pitches (e.g. 2.8 mm) are filed under the nearest class; see methodology.

Nominal vs exact pitch

“P” stands for pixel pitch, but vendors round the number for marketing. The exact values we store in our comparison tables: P2.6 is usually 2.604 mm, P3.9 / P3.91 is 3.906 mm, P2.9 is 2.976 mm. The exact figures come from dividing standard module sizes into whole LED counts — a 250 × 250 mm module at 3.906 mm holds exactly 64 × 64 LEDs.

Two cabinets both sold as “P3.9” can measure 3.906 mm or 3.91 mm: invisible in practice, but check the exact figure before mixing vendors on one wall. Some vendors also ship non-standard pitches (Desay’s TR2.5 at 2.583 mm, TR2.9 at 2.952 mm) — we flag these rather than silently filing them under P2.6 / P3.91.

How to choose

  • Start from the closest viewer, not the spec sheet maximum — use the calculator above. Beyond the viewing distance, extra resolution is invisible.
  • Content matters: text, tickers and control-room data need finer pitch; video and IMAG look fine one class coarser.
  • Indoor vs outdoor is decided by brightness and weatherproofing, not pitch — see the rental pitch guide.
  • On camera, refresh rate beats pitch: a 3,840 Hz P3.91 can outshoot a cheap low-refresh P2.6 — see broadcast studios.
  • Compare head to head: P2.6 vs P3.91, and houses of worship for the 2-meter-viewer case.
  • Full specifications: pitch is one of five spec categories — compare LED display specifications across 50 real models.

Frequently asked questions

What does P2.6 mean on an LED display?

P stands for pixel pitch: the center-to-center distance between adjacent LEDs, in millimeters. P2.6 means roughly 2.6 mm between LED centers; the exact figure vendors publish is usually 2.604 mm.

Why is P3.9 actually 3.906 mm?

The exact numbers come from dividing standard module sizes into whole LED counts: a 250 by 250 mm module at 3.906 mm pitch holds exactly 64 by 64 LEDs. Marketing rounds 3.906 down to 3.9 for sanity.

What pixel pitch do I need for my viewing distance?

Rule of thumb: minimum viewing distance in meters is roughly the pitch in millimeters. For viewers no closer than 4 meters, P3.91 (3.906 mm) is enough; for 2.5 meters and up, step finer to P2.6. Try the calculator above for a tailored recommendation.

Does a finer pixel pitch always look better on camera?

No. For camera work, refresh rate and grayscale matter more than pitch: a 3,840 Hz P3.91 can outshoot a cheap low-refresh P2.6 on camera.

Can I mix cabinets with slightly different exact pitches on one wall?

Two cabinets both sold as P3.9 can measure 3.906 mm or 3.91 mm. The difference is invisible in practice, but always check the exact pitch in the spec sheet before mixing vendors on one wall.

Which pixel pitch is most common?

In our catalog, the P1.9 class leads with 123 series, followed by P1.5 (102) and P3.91 (101). Fine-pitch indoor and the touring rental workhorse dominate the market, which matches what you see on real projects.

How many pixels per square meter does P2.6 have?

About 147,900 at the nominal 2.6 mm (147,475 at the exact 2.604 mm vendors publish). Pixel density follows a square law: (1000 / pitch)², so P1.9 packs roughly 277,000 pixels per m² while P3.91 packs about 65,500.

What pixel pitch do I need for outdoor billboards?

P5.9 and coarser in most cases. Viewing distances are long, so fine pitch buys nothing; outdoor duty is decided by brightness and weatherproofing (typically IP65), not by pitch. See the bottom rows of the ladder table.
