Indoor rental · 2.6 mm class

P2.6 rental LED cabinets, compared

Ten P2.6 indoor rental cabinets from ten manufacturers in one table: brightness, refresh rate, grayscale, cabinet size and weight, power, maintenance and IP rating, all transcribed from official vendor documents.

Last verified: 2026-09-26 · Specs transcribed from official vendor pages and spec sheets.

Concert crowd silhouettes under red stage lights
Illustrative photo: concert crowd under stage lighting.Photo by Cindy, CC BY 2.0, via Flickr

The short answer

Ten P2.6 indoor rental cabinets from ten manufacturers. Vendor-quoted brightness runs 600 to 1,500 nits; refresh rates run 3,840 to 7,680 Hz, with 7,680 Hz options from Absen, ROE, AOTO and QSTECH; 500 × 500 mm cabinets mostly weigh 5.5 to 9.5 kg. Every figure below is transcribed from official vendor documents, last verified 2026-09-26.

ProductPixel pitch (exact)BrightnessRefresh rateGrayscaleCabinet size / weightPower (max)MaintenanceIP rating
Absen SA2.6P2.6 *1,500 nits7,680 Hz16-bit1,000 × 500 × 70 mm / 500 × 500 × 70 mm · 9.5 kg / 5.5 kg540 W/㎡Front / rearIP40 / IP21
Unilumin URMIII 2.6P2.6 *1,000 cd/㎡3,840 Hz @6014-bit500 × 500 × 83 mm · 8 kg560 W/㎡RearIP30
Leyard LN2.62.604 mm1,000 nits3,840 Hz (7,680 Hz noted)16-bit500 × 500 × 79 mm / 500 × 1,000 × 79 mm · 7.5 kg / 13.5 kg600 W/㎡Rear (cabinet); modules front-serviceable (indoor version)IP50
ROE Visual Topaz TP2.62.604 mm1,500 nits (calibrated)7,680 Hz16-bit500 × 500 × 73 mm · 8.0 kg560 W/㎡Front / rearIndoor IP (per brochure)
INFiLED IRDB2.6-VSSP2.6 *1,000 to 1,500 nits3,840 Hz18-bit+ (HDR10)500 × 500 × 75.5 mm · 8.8 kgn/aFront / rear (magnetic modules)IP30
AOTO DL2.62.604 mmn/a7,680 Hzn/a500 × 500 mm (depth not stated) · 7.2 kg640 W/㎡n/an/a
QSTECH (Chipshow) C-Shine Plus 2.62.604 mm600 to 800 nits (indoor)7,680 Hz (indoor; ≥3,840 Hz across the line)≥14-bit500 × 500 mm (also 500 × 1,000 mm), 81 mm deep · ≤7 kg (500 × 500) / ≤14 kg (500 × 1,000)500 W/㎡Front / rear (5-second quick-release module)IP40 (indoor) / IP54 (outdoor)
LianTronics Pilot Plus 2.6P2.6 *800 nitsn/an/a500 × 500 × 80 mm · 8.5 kg/㎡ (as stated on official page)n/aRear (modules front/rear serviceable)n/a
Gloshine MV Ultra 2.6P2.6 *n/a3,840 Hz / 7,680 Hz14 to 16 bit500 × 500 × 76 mm · 8.5 kg (±10%)n/aFront / rearIP30
Yes Tech MU 2.6P2.6 *800 to 1,000 nits≥3,840 Hzn/a500 × 500 × 73 mm / 500 × 1,000 × 73 mm · 7.6 kg / 12.6 kg450 W/㎡ (±15%)Front / rearIP50

“n/a” means the figure was not found in the vendor’s public documents. * Pitch shown as the vendor’s nominal label; the exact mm value was not published. Why “P3.9” usually means 3.906 mm

Brightness at a glance

  • Absen SA2.61,500 nits
  • ROE Visual Topaz TP2.61,500 nits
  • Unilumin URMIII 2.61,000 nits
  • Leyard LN2.61,000 nits
  • INFiLED IRDB2.6-VSS1,000 nits
  • LianTronics Pilot Plus 2.6800 nits
  • Yes Tech MU 2.6800 nits
  • QSTECH (Chipshow) C-Shine Plus 2.6600 nits

8 of 10 products shown (2 omitted: figure not published). Vendor-quoted figures. ROE's 1,500 nits is a post-calibration figure while most vendors quote typical values, so the bars aren't strictly comparable across vendors.

Refresh rate at a glance

  • Absen SA2.67,680 Hz
  • ROE Visual Topaz TP2.67,680 Hz
  • AOTO DL2.67,680 Hz
  • QSTECH (Chipshow) C-Shine Plus 2.67,680 Hz
  • Unilumin URMIII 2.63,840 Hz
  • Leyard LN2.63,840 Hz
  • INFiLED IRDB2.6-VSS3,840 Hz
  • Gloshine MV Ultra 2.63,840 Hz
  • Yes Tech MU 2.63,840 Hz

9 of 10 products shown (1 omitted: figure not published).

Reading this table

  • Brightness: nits = cd/㎡. Note that ROE’s 1,500 nits is a post-calibration figure, while most vendors quote typical values, so they aren’t strictly comparable (see methodology).
  • Power: normalized to W/㎡. Vendors that quote per-cabinet watts (Unilumin, ROE, AOTO) were converted using the cabinet’s footprint; the original figure is kept on each product page.
  • Weight: listed as stated by the vendor; some include PSU/receiving card, some don’t. We don’t force them into one number.

Coverage gaps

These manufacturers have no P2.6 indoor rental cabinet line in public channels. That’s information, not an omission:

  • Daktronics: No P2.6 or P3.91 indoor rental cabinet line found in public channels. The current indoor line is fixed-install oriented (NPN/DVN/LVN series); the rental PST series is legacy (2009 to 2011). Closest 3.9 mm indoor product is the LVN-2010 fixed-install module (3.9 mm pitch, 1,500 nits, front maintenance), which is not a rental cabinet. Source
  • Desay: No P2.6 / P3.91 indoor rental product found. The closest rental line is the ultra-slim TR series in non-standard pitches: TR1.9 (1.968 mm), TR2.5 (2.583 mm), TR2.9 (2.952 mm). Source

Individual product pages

Frequently asked questions

Which P2.6 cabinets in this table have the highest refresh rate?

Four reach 7,680 Hz: Absen Saturn SA2.6, ROE Topaz TP2.6, AOTO DL2.6 and QSTECH C-Shine Plus (indoor). The rest of the table sits at 3,840 Hz. High refresh matters for broadcast and virtual production work.

What brightness do P2.6 rental cabinets typically quote?

Vendor-quoted figures in this table run from 600 nits (QSTECH C-Shine Plus, indoor) to 1,500 nits (Absen Saturn SA2.6, ROE Topaz TP2.6). Note that ROE’s 1,500 nits is a post-calibration figure while most vendors quote typical values, so the numbers aren’t strictly comparable across vendors.

How much does a P2.6 rental cabinet weigh?

At the standard 500 × 500 mm footprint, cabinets in this table weigh 5.5 to 9.5 kg: Absen Saturn’s 500 × 500 cabinet is lightest at 5.5 kg, AOTO DL2.6 is 7.2 kg, and most others land between 7.5 and 9.5 kg.

What is the minimum viewing distance for P2.6?

Use the rule of thumb: minimum viewing distance in meters is roughly the pitch in millimeters, so about 2.6 meters for P2.6. Closer than that and individual pixels become visible.

Where do these P2.6 specs come from?

Every figure is transcribed from the manufacturer’s official product page or spec sheet, linked in the Source column of each row, and was last verified 2026-09-26. Values not published by the vendor show as n/a; nothing is estimated.

Choosing between pitches? P2.6 vs P3.91 for rental & staging
